R57
Additional Information
Flexible Financing Offers Available
Description
General
| Machine Working Weight | 12566 lbs | 5700 kg |
| Multi-Way Valve | HYTEK | — |
| Hydraulics Pump | HYTEK | — |
| Travel Motor Brand | ZHTE | — |
| Swing Motor | Fujikoshi | — |
| Bucket Capacity | 3.2–6.2 ft³ | 0.09–0.175 m³ |
| Boom Length | 118.1 in | 3000 mm |
| Arm Length | 63 in | 1600 mm |
| Swing Speed | 9 rpm | 9 rpm |
| Travel Speed | 2.6 / 1.4 mph | 4.16 / 2.3 km/h |
| Bucket Digging Force | 9891 lbf | 44 kN |
| Arm Digging Force | 6619 lbf | 29 kN |
| Cab Full Height | 101.6 in | 2580 mm |
| Fuel Tank Capacity | 19.3 gal | 73.0 L |
| Tail Turning Radius | 65 in | 1650 mm |
| Counterweight Ground Clearance | 27.5 in | 700 mm |
| Track Contact Surface | 100 in | 2540 mm |
| Track Full Width | 74 in | 1880 mm |
| Track Shoe Width | 15.7 in | 400 mm |
| Minimum Ground Clearance | 15.7 in | 400 mm |
| Maximum Digging Range | 242 in | 6150 mm |
| Maximum Digging Height | 227.6 in | 5780 mm |
| Maximum Digging Depth | 153.1 in | 3890 mm |
| Maximum Unloading Height | 159.8 in | 4060 mm |
| Engine Model | Yanmar 4TNV94L / 4TNV98C | — |
| Maximum Horsepower | 51 hp | 38.1 kW |
| Maximum Speed | 2200 rpm | 2200 rpm |
| Cooling Method | Water Cooling | Water Cooling |
